Connector Quick Start

This guide creates a local connector server from the App Connect template, registers it in the Developer Console, and verifies that the extension can call the mock connector.

Prerequisites

  • Node.js 16 or newer
  • npm or another JavaScript package manager
  • RingCentral account for the Developer Console and App Connect extension
  • A public tunnel for local testing, such as ngrok or lite-http-tunnel

1. Create A Connector Profile

Open the Developer Console and create a connector.

For a first test, provide:

Field Value
Connector name Your CRM/platform name.
Unique identifier Enter the short connector identifier. The Console may display a developer namespace before it, such as ringcentral_labs..
Connector server URL A temporary HTTPS URL. You can replace it after starting your local tunnel.
CRM URL/environment Any valid setup value for the connector profile.
Auth type API key is simplest for the template.

The connector is private by default and visible to your organization.

After creating the connector, copy the complete Unique Identifier shown by the Developer Console. The complete value includes any developer namespace added by the Console. For example, if the field displays the prefix ringcentral_labs. and you enter zendesk, the identifier used at runtime is ringcentral_labs.zendesk, not zendesk. The identifier is permanent after creation.

2. Scaffold A Connector Server

Use the CLI:

npx @app-connect/cli init my-crm-connector
cd my-crm-connector

The generated server includes:

  • src/app.ts, which registers the connector and creates the core Express app
  • src/connectors/myCRM.ts, which exports the connector interface functions
  • src/connectors/interfaces/*.ts, starter implementations backed by mock JSON files
  • .env.test, a local environment example

Open src/app.ts and replace the template platform key with the complete Unique Identifier copied from the Developer Console:

connectorRegistry.registerConnector(
  'ringcentral_labs.zendesk',
  zendeskConnector,
);

The first argument to registerConnector() MUST exactly match the complete Developer Console identifier, including its namespace. Do not substitute the display name or only the short CRM name.

If dependencies were not installed automatically:

npm install

Copy and edit the environment file:

cp .env.test .env

On Windows PowerShell:

Copy-Item .env.test .env

3. Start The Server

Run:

npm run dev

The template server registers myCRM with connectorRegistry.registerConnector('myCRM', myCRMConnector) and serves the core App Connect routes.

Before continuing, confirm that you replaced myCRM with the complete Developer Console Unique Identifier as described in step 2.

4. Expose The Server

Expose the local server with an HTTPS tunnel and update the Developer Console connector server URL to that tunnel URL.

The main repository includes scripts such as:

npm run tunnel

or:

npm run ngrok

Use whatever tunnel is available in your environment.

5. Test In App Connect

  1. Verify the platform lookup against your connector server, using the complete identifier:
curl "http://localhost:6066/implementedInterfaces?platform=ringcentral_labs.zendesk"

The request should return HTTP 200 with the connector's capability map. 2. Install or open the App Connect extension. 3. Sign in with the same RingCentral account. 4. Select your private connector profile. 5. Enter any API key for the template connector. 6. Make or receive a test call. 7. Refresh contact matching, create a contact if needed, and log the call.

The template uses mock JSON files, so the first lookup may not find a contact. After creating a contact and logging a call, the mock data should show the created records.

6. Replace The Mock Logic

Update the connector interfaces under src/connectors/interfaces/ or replace src/connectors/myCRM.ts with your own implementation.

Implement at least:

Then add optional features such as contact creation, message logging, user mapping, dispositions, licensing, or appointments as needed.

7. Keep Manifest And Code In Sync

The Developer Console manifest controls what the client shows. The server implementation controls what the backend can actually do.

Before testing a feature, verify both sides:

  • Developer Console's complete Unique Identifier exactly matches the first argument to connectorRegistry.registerConnector().
  • Manifest advertises the fields or feature.
  • Connector exports the matching interface.
  • /implementedInterfaces?platform=<complete-unique-identifier> reports the method as implemented.

Troubleshoot A Platform Lookup Failure

If selecting or connecting the connector appears to do nothing, inspect the browser network requests. An HTTP 400 response from /implementedInterfaces?platform=<complete-unique-identifier> commonly means that the client requested the Developer Console identifier but the server registered a different key.

Compare the two values character for character:

Developer Console Unique Identifier: ringcentral_labs.zendesk
Server registerConnector() key:       ringcentral_labs.zendesk

The namespace, punctuation, and letter casing MUST match. Correct the server registration key, restart the server, and repeat the curl verification above. Do not modify the Developer Console database or create a second connector to repair this mismatch.
